3 Ton Goodman Gas Furnace

3 Ton 14 SEER AC / 96% 80K Btu Down-flow Gas Furnace / Coil GSX140361 AC Condensing Unit GCES960804CN 80,000 Btu Natural Gas furnace CAPF3642C6 Coil for Upright Installation Thermostat **Any Questions? Call us at 888-877-9811** Features GSX140361 Energy efficient Scroll compressor Factory installed filter drier Factory installed suction line accumulator Service valves with sweat connections and easy access to gauge ports 10-year compressor. 10-year parts warranty. Copper tube/aluminum fin coil Fully charged R410A system Electric heat kit available as a field-installed option Heavy-gauge galvanized-steel cabinet with attractive Architectural Gray powder-paint finish Specifications – GSX140361 Tonnage 3.0 Ton Cooling Capacity (Btu) 36,000 Btu SEER / EER 14.0 / 12.0 Sound Level 74 DB Liquid Line / Valve Size 3/8” / 3/8” Suction Line / Valve Size 3/4” / 7/8” Drain Size 3/4 Voltage-HZ / Phase 208-230-60 / 1 Phase Max Breaker Size 30 Amps Refrigerant Type / Charge R410 A / 81 oz. Unit Dimensions 29" W x 29" D x 32 1/2" H Shipping / Operating Weight 180 / 162 Lbs. Features GCES96 Furnaces Heavy duty aluminized steel dual diameter tubular heat exchanger Stainless steel secondary heat exchanger Single stage gas valve Durable silicon nitride igniter Quiet single speed draft induced Self-diagnostic control board with constant memory fault code history output to a LED All models comply with California 40ng/j low NOx emission standard Color coded low voltage terminals Vertical or Horizontal ( requires CHPF coil ) installation Multi-speed blower motor Convenient left or right connection for gas and electrical service Specifications – GCES960804CN High Fire Input Btu 80,000 High Fire Output Btu 76,800 Available AC Up to 3 tons Supply Plenum Opening 19 1/2” W x 19 1/2” D Number of Burners 4 Voltage-HZ / Phase 208-230-60 / 1 Phase Max Breaker Size 15 Amps Unit Dimensions 21" W x 28 7/8" D x 34 1/2" H Shipping Weight 139 Lbs. Features CAPF3642C6 All aluminum evaporator coil Check flowrater Split seam for easy access Specifications – CAPF3642C6 Nominal Tons Up to 3 Liquid Connection 3/8” Suction Connection 3/4“ Unit Dimensions 21" W x 21" D x 22" H Shipping Weight 49 Lbs.

Returns Accepted for this item if it's within 30 Days
